Image preview - the first page of the document
08. Cowl Panel


>> Download 08. Cowl Panel documenatation <<

Text preview - extract from the document
                                                COWL PANEL
EXTERIOR/INTERIOR TRIM

8. Cowl Panel
A: REMOVAL
1) Open the front hood.
2) Remove the wiper arm.
3) Remove the front panel seal.




                                           EI-00450

4) Disengage the clips (A) to remove the cowl pan-
el.




        : (A)                              EI-00451

B: INSTALLATION
Install in the reverse order of removal.




                                                      EI-32
