Image preview - the first page of the document
10. Rear Spoiler


>> Download 10. Rear Spoiler documenatation <<

Text preview - extract from the document
                                              REAR SPOILER
EXTERIOR/INTERIOR TRIM

10.Rear Spoiler                                          B: INSTALLATION
                                                         1) Install in the reverse order of removal.
A: REMOVAL                                               2) Clean the mounting surfaces of trunk lid and
1) Disconnect the ground cable from battery.             spoiler before installation.
2) Open the trunk lid.
3) Remove the electrical connector (A) of high           Tightening torque:
mount stop light.                                          7.4 N
