Image preview - the first page of the document
13. Front Door Trim


>> Download 13. Front Door Trim documenatation <<

Text preview - extract from the document
                                         FRONT DOOR TRIM
EXTERIOR/INTERIOR TRIM

13.Front Door Trim                                     B: INSTALLATION
                                                       Install in the reverse order of removal.
A: REMOVAL
CAUTION:
Do not apply excessive force to the clip. Other-
wise the clip may be broken.
1) Disconnect the ground cable from battery.
2) Pull the inner remote cover toward you to re-
move upper hook. Pull down it to remove the lower
hook. Remove the inner remote cover.




                                        EI-00455

3) Remove the screw.
4) Remove the power window switch assembly and
disconnect the harness connector.




                                        EI-00457

5) Remove the screw.
6) Remove the clips (A) of trim panel using clip re-
mover to remove the trim panel.




          : (A)
                                        EI-00459




                                                   EI-38
