Image preview - the first page of the document
>> Download 14. Rear Door Trim documenatation <<
Text preview - extract from the document
REAR DOOR TRIM
EXTERIOR/INTERIOR TRIM
14.Rear Door Trim 5) Disconnect the power window harness connec-
tor.
A: REMOVAL
CAUTION:
Do not apply excessive force to the clip. Other-
wise the clip may be broken.
1) Disconnect the ground cable from battery.
2) Pull the inner remote cover toward you to re-
move the upper hook. Pull it down to remove the
lower hook. Remove the inner remote cover.
: (A)
EI-00463
(A) Clip
B: INSTALLATION
Install in the reverse order of removal.
EI-00455
3) Remove the screw and clip.
EI-00461
4) Remove the clips (A) of trim panel using clip re-
mover to remove the trim panel.
EI-39
