Image preview - the first page of the document



>> Download 16. Roof Rail documenatation <<

Text preview - extract from the document

                                              ROOF RAIL
                                                                             EXTERIOR/INTERIOR TRIM

16.Roof Rail
A: REMOVAL
1) Remove the roof trim.
2) Remove the four mounting nuts, and then detach the roof rail carefully.




                                                                                               EI-00467

B: INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be careful not to scratch the body panels with roof rail stud bolts when removing and installing them.
Tightening torque:
  7.4 N
