Image preview - the first page of the document



>> Download 18. Console Box documenatation <<

Text preview - extract from the document

                                           CONSOLE BOX
                                                                               EXTERIOR/INTERIOR TRIM

18.Console Box                                        4) Loosen the screws to remove the console box.

A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the console cover.




        : (A)         : (B)
                                       EI-00468


      (A) Hook pawl
      (B) Clip

3) Remove the shift knob (MT model) and front
cover.
                                                                                                 EI-00470

                                                      B: INSTALLATION
                                                      Install in the reverse order of removal.




       : (A)
                                       EI-00469


      (A) Hook pawl




                                                  EI-43
