Image preview - the first page of the document
>> Download 22. Rear Quarter Trim documenatation <<
Text preview - extract from the document
REAR QUARTER TRIM
EXTERIOR/INTERIOR TRIM
22.Rear Quarter Trim 6) Loosen the bolts and clips to remove the rear
quarter lower trim (D).
A: REMOVAL
1. SEDAN MODEL (B) (A)
1) Remove the rear seat.
2) Remove the side sill rear cover.
3) Remove the rear pillar lower cover (A).
4) Remove the seat belt lower anchor bolt, and
then remove the rear pillar upper trim (B).
(B)
(C)
(A)
(D)
: (C)
EI-00497 : (E)
EI-00498
(C) Clip
(E) Clip
2. WAGON MODEL
1) Remove the rear seat. Install in the reverse order of removal.
2) Remove the side sill rear cover. CAUTION:
3) Remove the rear rail trim (A). Be sure to securely hook the pawls of inner trim
4) Loosen the screws and clips to remove the rear panel to body flange.
quarter upper trim (B).
5) Remove the rear skirt trim (C). NOTE:
When installing the rear quarter upper trim, be sure
to set the rear molding as shown in the figure.
(A) (B)
(C)
(D)
(E)
(F)
EI-00071
(A) Outside
(B) Inside
(C) Molding
(D) Weather strip
(E) Trim
(F) Body
EI-49
