Image preview - the first page of the document
31. Heat Shield Cover


>> Download 31. Heat Shield Cover documenatation <<

Text preview - extract from the document
                                           HEAT SHIELD COVER
                                                               EXTERIOR/INTERIOR TRIM

31.Heat Shield Cover
A: REMOVAL
1. FRONT HEAT SHIELD COVER
Loosen the four bolts to remove the front heat
shield cover.

             (A)




                                           DI-00211


       (A) Transmission mount

2. CENTER HEAT SHIELD COVER
Loosen the four bolts to remove the center heat
shield cover.




                                           EI-00107

3. REAR HEAT SHIELD COVER
1) Remove the muffler. ,
2) Loosen the four bolts to remove the rear heat
shield cover.




                                           EI-00108

B: INSTALLATION
Install in the reverse order of removal.


                                                      EI-59
                         HEAT SHIELD COVER
EXTERIOR/INTERIOR TRIM




                               EI-60
