Image preview - the first page of the document



>> Download 08. Trunk Lid Panel documenatation <<

Text preview - extract from the document

                                          TRUNK LID PANEL
                                                                                  EXTERIOR BODY PANELS

8. Trunk Lid Panel                                      B: INSTALLATION
A: REMOVAL                                              1. TRUNK LID
1. TRUNK LID                                            1) Install in the reverse order of removal.
                                                        2) Install the trunk lid with uniform clearance.
1) Open the trunk lid.
2) Disconnect the trunk lid connector.                  Tightening torque:
3) Loosen the trunk lid mounting bolts to remove          14 N
