Image preview - the first page of the document



>> Download 09. Rear Gate Panel documenatation <<

Text preview - extract from the document

                                         REAR GATE PANEL
EXTERIOR BODY PANELS

9. Rear Gate Panel                                     CAUTION:
                                                       When the rear gate is released, it may hit and
A: REMOVAL                                             damage the body. To prevent this, place a shop
1. REAR GATE PANEL                                     cloth between the body and gate.
                                                       10) Loosen the rear gate bolts to remove rear gate.
1) Disconnect the ground cable from battery.
2) Open the rear gate.
3) Remove the rear gate outer handle.
4) Remove the rear gate latch assembly.
5) Remove the rear wiper.
6) Disconnect the connectors of rear wiper, rear
defogger and other lighting devices.
7) Disconnect the washer hose.                                                                EB-00023
8) Remove the rubber duct (A) connection, and
then pull out the harness and washer hose from
rear gate.




                                  (A)




                                        EB-00020

9) Using a support, support the rear gate while re-
moving the rear gate damper stay mounting bolts.




                                        EB-00021




                                        EB-00129




                                                   EB-22
                                       REAR GATE PANEL
                                                                               EXTERIOR BODY PANELS

2. REAR GATE DAMPER STAY                             B: INSTALLATION
1) Open the rear gate. Use a jack to support the     1. REAR GATE PANEL
rear gate.
                                                     1) Install in the reverse order of removal.
                                                     2) Install the rear gate panel with uniform clearance
                                                     to the body.
                                                     Refer to COMPONENT of General Description for
                                                     tightening torque.
                                                     CAUTION:
                                                     Do not damage the painted surfaces of body
                                                     and rear gate panel.
                                      EB-00021       2. REAR GATE DAMPER STAY
NOTE:                                                1) Install the mounting bolt (A) to the rear gate and
                                                     body.
After the rear gate damper stay is removed, the
rear gate cannot stay open. Supporting the rear      Tightening torque:
gate with a jack, remove the bolts.                     19.6 N
