Image preview - the first page of the document



>> Download 05. Subaru Select Monitor documenatation <<

Text preview - extract from the document

                                   SUBARU SELECT MONITOR
CRUISE CONTROL SYSTEM (DIAGNOSTICS)

5. Subaru Select Monitor                               2) Connect the diagnosis cable to Subaru Select
                                                       Monitor.
A: OPERATION                                           3) Insert the cartridge into Subaru Select Monitor.

The on-board diagnosis function of the cruise con-
trol system uses the Subaru Select Monitor.
The on-board diagnosis function operates in two
categories, which are used depending on the type
of problems;
1) Cruise cancel conditions diagnosis:
    (1) This category of diagnosis requires actual
    vehicle driving in order to determine the cause,
    (as when cruise speed is cancelled during driv-
    ing although cruise cancel condition is not en-
    tered).                                                                                     CC-00029
    (2) Cruise control module memory stores the        4) Connect the Subaru Select Monitor to data link
    cancel condition (Code No.) which occurred dur-    connector.
    ing driving. When there are plural cancel condi-      (1) Data link connector is located in the lower
    tions (Code No.), they are shown on the Subaru        portion of the instrument panel (on the driver's
    Select Monitor.                                       side).
CAUTION:
