Image preview - the first page of the document



>> Download 01. General Description documenatation <<

Text preview - extract from the document

                                         GENERAL DESCRIPTION
CRUISE CONTROL SYSTEM

1. General Description
A: COMPONENT
                                       (3)
                                                                   (2)


                                                                                           (1)




                          (5)
                                         (4)




                                                                                                                          CC-00196


 (1)   Engine control module (ECM)           (3)   Cruise indicator light & cruise set   (4)     Stop light and brake switch
 (2)   Cruise control command switch               indicator light                       (5)     Clutch switch
       (with built-in main switch)

B: CAUTION
