>> Download 03. Crossbar documenatation <<

Text preview - extract from the document

                                                            CROSSBAR
OPTION PARTS

3. Crossbar                                                      4) Set the rear crossbar so that front direction mark
                                                                 on the right side top face of crossbar point in the di-
A: REMOVAL                                                       rection of vehicle front.
1) Remove the TORX bolt T30 from each end                        5) Place the crossbar end support on a joint of rear
support.                                                         roof rail support and roof rail.
2) Rotate the lower clamp of each end support
about 90
