Image preview - the first page of the document



>> Download 04. Trailer Hitch documenatation <<

Text preview - extract from the document

                                             TRAILER HITCH
                                                                                          OPTION PARTS

4. Trailer Hitch                                       5) Remove the trailer hitch while lowering exhaust
                                                       pipe.
A: REMOVAL                                             B: INSTALLATION
CAUTION:
Because the trailer hitch is heavy, two people         CAUTION:
are required to remove it.                             Because the trailer hitch is heavy, two people
                                                       are required to install it.
1) Lift-up the vehicle.
                                                       Install in the reverse order of removal.
2) Remove the cushion rubber from body.
                                                       Tightening torque:
                                                         Trailer hitch to body:
                                                           95 N
