Image preview - the first page of the document
>> Download 49. Harness Components Location documenatation <<
Text preview - extract from the document
HARNESS COMPONENTS LOCATION
WIRING SYSTEM
49.Harness Components Location
A: LOCATION
(10)
(6)
(5)
(8)
(9)
(4)
(2) (11)
(13)
(7)
(12)
(14)
(1) (3)
(7)
WI-02775
(1) Front wiring harness (6) Rear door cord RH (11) Trunk lid cord
(2) Engine wiring harness (7) Rear wiring harness (12) Front door cord LH
(3) Bulkhead wiring harness (8) Roof cord (13) Transmission cord
(4) Instrument panel wiring harness (9) Fuel tank cord (14) Rear door cord LH
(5) Front door cord RH (10) Rear gate cord
WI-171
