Image preview - the first page of the document
>> Download 05. Valve Rocker Assembly documenatation <<
Text preview - extract from the document
W1860BE.book Page 7 Tuesday, January 28, 2003 11:01 PM
VALVE ROCKER ASSEMBLY
MECHANICAL
5. Valve Rocker Assembly
The intake valve rocker arms and the exhaust valve rocker arms are installed on their own rocker
shafts both of which are retained by the camshaft caps.
The valve end of each rocker arm is provided with valve rocker adjusting screw and nut. Turning
of this screw adjusts the valve clearance.
The exhaust valve rocker arms are Y-shaped, and each arm operates two exhaust valves simul-
taneously.
Each rocker shaft has an oil passage in it.
(1) (2) (3) (1) (2) (3) (4)
(5) (1) (6) (1) (6) (5)
ME-00316
(1) Valve rocker adjusting screw and nut (4) Camshaft cap
(2) Intake valve rocker arm (5) Supporter
(3) Wave washer (6) Exhaust valve rocker arm
ME(H4SO)-7
