Image preview - the first page of the document
>> Download 07. Cylinder Head documenatation <<
Text preview - extract from the document
W1860BE.book Page 9 Tuesday, January 28, 2003 11:01 PM
CYLINDER HEAD
MECHANICAL
7. Cylinder Head
The cylinder head is made of aluminum die casting.
Each combustion chamber in the cylinder head is a compact, pentroof design. The spark plug is
located at the center of the combustion chamber, which contributes to creation of a wide "squish
area" for increased combustion efficiency.
The two intake and two exhaust valves are arranged on opposite sides for a cross-flow feature.
The cylinder head gasket is a metallic gasket. The gasket is highly resistant to heat and maintains
high level of sealing performance for a long period.
(1) (2) (3)
(4) (1)
(6) (7)
(6) (5)
ME-00318
(1) Intake valve (5) Exhaust port
(2) Intake port (6) Exhaust valve
(3) Squish area (7) Spark plug
(4) Combustion chamber
ME(H4SO)-9
