Image preview - the first page of the document
>> Download 06. Radiator Fan documenatation <<
Text preview - extract from the document
W1860BE.book Page 8 Tuesday, January 28, 2003 11:01 PM
RADIATOR FAN
COOLING
6. Radiator Fan
A: DESCRIPTION
Each radiator fan is made of plastic. It is driven by an electric motor which is retained on a shroud.
(18) (16)
(17)
(6) (5)
(4) (7)
(3)
(11)
(14) (20)
(8)
(15)
(1) (2)
(9)
(13)
(10)
(12)
(19)
CO-00244
CO(H4DOTC)-8
W1860BE.book Page 9 Tuesday, January 28, 2003 11:01 PM
RADIATOR FAN
COOLING
(1) Radiator (12) Lower cushion
(2) Radiator sub fan (models with A/C) (13) Drain plug
(3) Radiator sub fan motor (models with A/C) (14) Upper bracket
(4) Radiator sub fan shroud (models with A/C) (15) Upper cushion
(5) Overflow hose (A) (16) Radiator cap (coolant filler tank cap)
(6) Overflow pipe (17) Coolant filler tank
(7) Reservoir tank cap (18) Coolant hose
(8) Reservoir tank (19) Lower bracket
(9) Radiator main fan shroud (20) Overflow hose (B)
(10) Radiator main fan
(11) Radiator main fan motor A/C: Air conditioning system
CO(H4DOTC)-9
W1860BE.book Page 10 Tuesday, January 28, 2003 11:01 PM
RADIATOR FAN
COOLING
B: FUNCTION
1. MODELS WITHOUT A/C
The ON-OFF control and Hi-Low control of the radiator fan is performed by the ECM which receives
signals from the engine coolant temperature sensor.
Vehicle speed Engine coolant temperature
Lower than 90◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
