Image preview - the first page of the document
>> Download 04. 2-4 Brake documenatation <<
Text preview - extract from the document
W1860BE.book Page 8 Tuesday, January 28, 2003 11:01 PM
2-4 BRAKE
AUTOMATIC TRANSMISSION
4. 2-4 Brake
A: CONSTRUCTION
The 2-4 brake consists of a 2-4 brake piston, a return spring, a pressure plate, drive plates and driv-
en plates.
This brake is engaged by the hydraulic pressure from the transmission control valve and locks the
front sun gear when the 2nd gear is selected in the D, 3 or 2 range, or when the 4th gear is selected
in the D range.
(7)
(6)
(4)
(5)
(4)
(5)
(4)
(3)
(2)
(13)
(12)
(11)
(10)
(1)
(9)
(8) AT-00467
(1) Leaf spring (6) Pressure rear plate (10) D-ring
(2) Snap ring (7) Snap ring (11) D-ring
(3) Retaining plate (8) Return spring (12) 2-4 brake piston seal
(4) Drive plate (9) 2-4 brake piston (13) 2-4 brake piston retainer
(5) Driven plate
4AT-8
