Image preview - the first page of the document



>> Download 01. Rear Differential documenatation <<

Text preview - extract from the document

W1860BE.book Page 2 Tuesday, January 28, 2003 11:01 PM




                                                         REAR DIFFERENTIAL
 DIFFERENTIALS


 1. Rear Differential
 A: EXCEPT STi MODELS
 The drive gear is a hypoid gear with nominal diameter of 160 mm (6.30 in). The drive pinion shaft
 is supported by three bearings. The bearing preload is adjusted by selecting a spacer and washer
 combination of a proper thickness. The drive pinion height is adjusted by properly selecting the
 thickness of the washers located at the drive pinion neck using a dummy shaft and gauge.




                                                                                          DI-00231




                                                               DI-2
W1860BE.book Page 3 Tuesday, January 28, 2003 11:01 PM




                                                              REAR DIFFERENTIAL
                                                                                                     DIFFERENTIALS


           B: STi MODELS
           The drive gear is a hypoid gear with nominal diameter of 180 mm (7.09 in). The drive pinion shaft
           is supported by three bearings. The bearing preload is adjusted by selecting a spacer and washer
           combination of a proper thickness. The drive pinion height is adjusted by properly selecting the
           thickness of the washers located at the drive pinion neck based on the value stamped on the drive
           pinion shaft rear end.
           To deal with the enhanced engine power, the diameter of the companion flange (joint to the propeller
           shaft) is increased for additional rigidity.
           Moreover, the rear differential oil temperature switch opens when the rear differential oil temperature
           exceeds 150
