05. Trunk Lid Release Handle


>> Download 05. Trunk Lid Release Handle documenatation <<

Text preview - extract from the document
W1860BE.book Page 8 Tuesday, January 28, 2003 11:01 PM




                                                 TRUNK LID RELEASE HANDLE
 SECURITY AND LOCKS


 5. Trunk Lid Release Handle
 A: GENERAL
     The trunk lid release handle is a device designed to open the trunk lid from inside the trunk.
   In the event children or adults become locked inside the trunk, the handle allows them to open
 the lid.
     The handle is located on the inside of the trunk lid.
    The handle is made of material that remains luminescent for approximately an hour in the dark
 trunk space after it is exposed to ambient light event for a short time.




                                                                                  SL-00168


 B: OPERATION
 To open the trunk lid from inside the trunk, press the yellow handle downward as indicated by the
 arrow on the handle, this operation unlocks the trunk lid. Then push up the lid.




                                                                       SL-00169
