Image preview - the first page of the document
>> Download 17-04-9934511 documenatation <<
Text preview - extract from the document
ATTENTION:
GENERAL MANAGER PARTS MANAGER
CLAIMS PERSONNEL SERVICE MANAGER
IMPORTANT - All Service Personnel Should Read and Initial
SERVICE BULLETIN
APPLICABILITY: All Subaru Vehicles Equipped with child NUMBER: 17-04-99
Restraint Top Tether Anchor Points DATE: 11/17/99
SUBJECT: Installation of Top Tether Anchor Kits
Effective with vehicles produced on or after September 1, 1999, in accordance with Federal Motor
Vehicle Safety Standard 225, all Subaru vehicles will be equipped with top tether anchor hooks for use
with forward facing child restraint seats and booster seats. All 2000 model year Subaru vehicles will be
equipped in production with 3 top tether anchor hooks. The tether strap that connects the top of the
child restraint to the anchor hook must be supplied by the manufacturer of the child restraint.
TOP TETHER ANCHOR KITS FOR OLDER MODELS
This new requirement for 2000 model year vehicles may cause customer demand for installation of top
tether anchor kits on earlier model vehicles. You should be prepared to install these factory supplied top
tether anchor kits on customer request in 1985 and later Subaru vehicles. Anchor kits are not available
for 1987 and 1988 Justy models (which began in 1989MY) in accordance with the attached Chart 1.
Installation instructions are included with the anchor kit. Anchor points are shown in Figures 1 through 5
for all models. On 1995 through 1999 Legacy Sedan vehicles, the package shelf material is not cut out
at the anchor pint location. You must locate the threaded anchor point from the trunk side of the
package shelf and cut out the package shelf material to accommodate the anchor kit bolt.
Chart 1- ANCHOR KIT APPLICATION
Part Number MY Model/Application Note
796031110 89-94 Justy Gray
96031AA080BI 90-91 Legacy (SED) Blue
96031AA080BK 92-94 Legacy (SED) Blue
96031AA080EL 90-91 Legacy (SED) Beige
96031AA080EM 92-94 Legacy (SED) Beige
96031AA080LM 90-91 Legacy (SED) Gray
96031AA080MJ 92-94 Legacy (SED) Gray
96031AA080ML 93-94 Legacy (SED) Black
96031AA090BI 90-91 Legacy (WAG) Blue
96031AA090BK 92-94 Legacy (WAG) Blue
Continued on next page...
CAUTION
VEHICLE SERVICING PERFORMED BY UNTRAINED PERSONS COULD RESULT IN SERIOUS INJURY TO THOSE PERSONS OR TO OTHERS.
Subaru Service Bulletins are intended for use by professional technicians ONLY. They are written to inform those technicians of conditions that may occur in some vehicles, or to provide
information that could assist in the proper servicing of the vehicle. Properly trained technicians have the equipment, tools, safety instructions, and know-how to do the job correctly and safely.
If a condition is described, DO NOT assume that this Service Bulletin applies to your vehicle, or that your vehicle will have that condition.
Number: 11-54-99; Date 11/17/99 Page 2
Part Number MY Model/Application Note
96031AA090EL 90-91 Legacy (WAG) Beige
96031AA090EM 92-94 Legacy (WAG) Beige
96031AA090LM 90-91 Legacy (WAG) Gray
96031AA090MJ 92-94 Legacy (WAG) Gray
96031AA090ML 92-94 Legacy (WAG) Black
96031AC000MU 95-99 Legacy (SED) Dark Gray
96031AC000RA 95-99 Legacy (SED) Reddish Gray
96031AC070 95-99 Legacy (WAG) Dark Gray
96031AC080 95-99 Legacy (WAG) Reddish Gray
96031FA000EM 93-99 Impreza (SED & CPE) Beige
96031FA000MJ 93-99 Impreza (SED & CPE) Gray
96031FA010EM 93-99 Impreza (WAG) Beige
96031FA010MJ 93-99 Impreza (WAG) Gray
96031GA060BE 85-94 Leone/Loyale (3DR & WAG) Blue
85-89 2DR HB
96031GA060LR 85-94 Leone/Loyale (3DR & WAG) Gray
85-89 2DR HB
96031GA070BE 85-93 Leone/Loyale (SED) Blue
85-89 XT
96031GA070LR 85-93 Leone/Loyale (SED) Gray
85-91 XT & XT6
96031PA000 92-97 SVX Gray
96031PA030 92-97 SVX Beige
96030FC110 98-99 Forester Gray
96030FC120 98-99 Forester Beige
INSTALLATION OF ANCHOR KIT
1. Remove the various pieces of the anchor kit from the package and assemble the anchor bolt
through the anchor bracket, spacer and washer (Figure 6).
2. Remove the cover (or cut the package shelf material on 1995-1999 Legacy Sedan) from the
anchor installation point on the vehicle. Install the assembled anchor kit (Figure 6) directly behind
the seating position to be utilized for the child restraint as shown in the attached Figures (1 thru 5)
for the particular model and screw the anchor bolt into the threaded anchor point on the vehicle.
Tighten the anchor bolt to 20 foot pounds with a torque wrench.
3. Install the anchor plate cover (Figure 6).
4. Refer the owner to the Child Restraint System section (Section 2) of the Owners Manual for
instructions on how to attach the child restraint top tether strap hook to the anchor.
Number: 17-04-99; Date 11/17/99 Page 3
FIGURE 1- Anchor Points for Legacy Sedan and Wagon, Loyale Sedan
and Wagon and Impreza Sedan
FIGURE 2- Impreza Wagon Anchor Points
FIGURE 3- Justy Anchor Points
FIGURE 4- Loyale 3-Door Anchor Points
Number: 11-54-99; Date 11/17/99 Page 4
FIGURE 5-2 Door Hatchback Anchor Points
FIGURE 6- Assembly of Anchor Kit
All Models Except
Justy Cover
Anchor bolt
(5/16in.)
Anchor bracket
Spacer
Washer
Justy
Bolt assembly (5/16in)
Anchor plate
Setting washer
Number: 17-04-99; Date 11/17/99 Page 5
FIGURE 7- Anchor Kit Installation
Legacy, Legacy Outback
Loyale, Impreza Sedan &
Impreza Coupe
Forester
Impreza Wagon &
Outback Sport
