Image preview - the first page of the document
>> Download MSA5T9713A34484 documenatation <<
Text preview - extract from the document
Connector Connecting to
No . Pole Color Area No . Name
i1 22 Black C-4 B36
i2 22 G4 B37
Bulkhead wiring harness
i3 22 Brown C-4 B38
i4 20 Blue C-4 B39
i5 15 Gray C-4 F!B
i6 10 C-4 Remote control rearview mirror switch
i10 16 Light gray B-3
Combination meter
i11 5 Light blue B-3
i12 16 Light gray B-3 Combination meter
04 13 B-3 Combination meter
05 6 B-2 Fan switch
07 16 Black B-2 Mode control panel
08 6 B-3 Rear defogger switch
09 6 Brown B-3 Cruise control main switch
i20 4 Blue B-2 B80 Bulkhead wiring harness
i22 10 B-2 Hazard switch
i23 2 Brown B-2 Glove box illumination light
i24 1 G2
Front accessory power supply
i25 3 C-2
i26 14 B-2 Radio
i27 2 B-2 CD player illumination light
i28 1 Black C-2 Ground
i29 1 Black C-2 Ground (Radio)
i30 4 B-2 Rear window defogger timer
' : Non-colored
5
[D805]
5. INSTRUMENT PANEL WIRING HARNESS AND GROUND POINT
e RHD model
1 I 2 I 3 4
A A
B B
C C
D C
B6M0849A
1 2 3 4
Connector Connecting to
No. Pole Color Area No . Name
i1 22 Black C-2 B36
i2 22 C-1 B37
Bulkhead wiring harness
i3 22 Brown C-1 B38
i4 20 Blue C-2 B39
i5 15 Gray C-1 F1B
i6 10 C-1 Remote control rearview mirror switch
i7 6 Yellow B-2 Front fog light switch
i8 4 Brown B-2 Security indicator light
i9 6 B-2 TCS off switch
i10 16 Light gray B-2
Combination meter
i11 5 Light blue B-2
i12 16 Light gray B-2 Combination meter
i14 13 B-2 Combination meter
05 6 B-3 Fan switch
06 3 B-3 A/C switch
07 16 B-3 Mode control panel
08 6 B-3 Rear defogger switch
09 6 Brown B-2 Cruise control main switch
i20 4 Blue B-3 B80 Bulkhead wiring harness
i21 2 Black C-3 Ash tray illumination light
i22 10 B-3 Hazard switch
i23 2 Brown B-4 Glove box illumination light
i24 1 C-3
Front accessory power supply
i25 3 C-3
i26 14 B-3 Radio
i27 2 B-3 CD player illumination light
i28 1 Black C-3 Ground
i29 1 Black G3 Ground (Radio)
