Image preview - the first page of the document
>> Download 041mr documenatation <<
Text preview - extract from the document
MOON ROOF
FROM POWER SOURCE SYSTEM (SEE PAGE 48)
1
30A 10A
POWER ECU- IG
2
3 10
POWER ECU- IG
B16 A
L- R
BODY ECU
P/W GND DCTY M3
19 A 2 MOON ROOF CONTROL RELAY AND SW
2 8
IG
CLOSE/
DOWN
OPEN/
B
5 1
UP
L- R
PWR RELAY
3 2
DOOR COURTESY
1
SW FRONT LH
6 1A 8 1J
D16
L- R
L- R
LS. 1 LS. 2 MOTOR+ MOTOR- GND
6 7 4 5 8
W- B
L- W
R- L
W
R
W- B
5 4 2 1
NO. 1
NO. 2
M
3 M2
MOON ROOF CONTROL MOTOR
AND LIMIT SW
W- B
W- B
B3
21 3E
W- B
16 3E
2 IH1
W- B
W- B
A A
J9 J4
JUNCTION JUNCTION
CONNECTOR CONNECTOR
IF IE
2002 4RUNNER (EWD471U)
164
SYSTEM OUTLINE
Current is applied at all times through the POWER fuse to TERMINAL 5 of the PWR relay.
With the ignition SW turned on, the current flows from TERMINAL 1 of the PWR relay to TERMINAL 2 to GROUND through
the ECU-IG fuse. As a result, the PWR relay is activated and the current to TERMINAL 5 of the PWR relay flows from
TERMINAL 3 of the relay to TERMINAL 2 of the moon roof control relay and SW.
1. SLIDE OPEN OPERATION
When the ignition SW is turned on and the moon roof control SW is pushed to the OPEN position, a signal is input to HALL
IC of the moon roof control relay and SW. The moon roof limit SW no. 2 is turned on at this time.
This activates the moon roof control relay and SW and rotates the motor to fully open the moon roof automatically. If other
operation SW or the open SW is operated while the moon roof is being opened, the moon roof control relay and SW is
activated to stop the moon roof operation.
2. SLIDE CLOSE OPERATION
With the ignition SW turned on, moon roof completely open and the moon roof limit switch no. 1 and no. 2 both are on, when
the moon roof control SW is pushed to the CLOSE position, a signal is input to HALL IC of the moon roof control relay and
SW.
When this occurs, the relay is activated and the current to TERMINAL 2 of the moon roof control relay and SW flows from
TERMINAL 4 to TERMINAL 2 of the moon roof control motor to TERMINAL 1 to TERMINAL 5 of the moon roof control relay
and SW to TERMINAL 8 to GROUND, rotating the motor to close the moon roof while the SW is being pushed to CLOSE
position.
When the moon roof limit SW no. 1 is turned off (The moon roof limit SW no. 2 is on), and moon roof reaches 100mm from
fully close position, signal is input from TERMINAL 5 of the moon roof limit SW to TERMINAL 6 of the moon roof control relay
and SW. This signal activates the relay and stops continuity from TERMINAL 2 of the moon roof control relay and SW to
TERMINAL 8, as a result, the moon roof stops at this position.
To close the moon roof completely, pushing the moon roof control SW again to the close side causes a signal to be input
again to HALL IC of the moon roof control relay and SW. This activates the relay and the moon roof will close as long as the
moon roof control SW is being pushed, allowing the moon roof to fully close.
3. TILT UP OPERATION
When the moon roof control SW is pushed to UP position, with the ignition SW turned on and the moon roof completely
closed (Moon roof limit SW no.2 is off), a signal is input to HALL IC of the moon roof control relay and SW. As a result, the
relay is activated and the current to TERMINAL 2 of the moon roof control relay and SW flows from TERMINAL 4 of the
moon roof control relay and SW to TERMINAL 2 of the moon roof control motor to TERMINAL 1 to TERMINAL 5 of the moon
roof control relay and SW to TERMINAL 8 to GROUND, rotating the motor so that tilt up operation occurs as long as the
moon roof control SW is pushed on the tilt up side.
4. TILT DOWN OPERATION
When the moon roof control SW is pushed to DOWN position, with the ignition SW turned on and the moon roof tilted up
(The moon roof limit SW no.1 and no.2 are both off.), a signal input to HALL IC of the moon roof control relay and SW.
As the result, the moon roof control relay is activated and the current to TERMINAL 2 of the moon roof control relay and SW
flows from TERMINAL 5 of the moon roof control relay and SW to TERMINAL 1 of the moon roof control motor to TERMINAL
2 to TERMINAL 4 of the moon roof control relay and SW to TERMINAL 8 to GROUND, rotating the motor so that tilt down
operation occurs as long as the moon roof control SW is pushed on the tilt down side. (During tilt down, the moon roof limit
SW no. 1 is changes off to on.)
5. KEY OFF MOON ROOF OPERATION
With the ignition SW turned from on to off, the body ECU operates and the current flows from the POWER fuse to
TERMINAL 3 of the body ECU to TERMINAL 2 to TERMINAL 1 of the PWR relay to TERMINAL 2 to GROUND, at this time,
for about 43 seconds the same as normal operation, the current flows from the POWER fuse to TERMINAL 5 of the PWR
relay to TERMINAL 3 to TERMINAL 2 of the moon roof control relay and SW. As a result, for about 43 seconds after the
ignition SW is turned off, the function of this relay makes it possible to open and close the moon roof. Also, by opening the
front door LH (Door courtesy SW front LH on) within about 43 seconds after turning the ignition SW to off, a signal is input to
TERMINAL (A) 19 of the body ECU. As a result, the relay turns off, and open and close, movement of the moon roof stops.
2002 4RUNNER (EWD471U)
165
MOON ROOF
SERVICE HINTS
PWR RELAY
5-3 : Closed with the ignition SW at ON position or key off operated
M3 MOON ROOF CONTROL RELAY AND SW
8-GROUND : Always continuity
2-GROUND : Approx. 12 volts with the ignition SW at ON position or key off operated
4-GROUND : Approx. 12 volts with the ignition SW on and the moon roof control SW at CLOSE or UP position
5-GROUND : Approx. 12 volts with the ignition SW on and the moon roof control SW at OPEN or DOWN position
: PARTS LOCATION
Code See Page Code See Page Code See Page
B16 A 30 J4 31 M2 33
D16 32 J9 31 M3 33
,,,
,,, : JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
,,,
Code See Page Junction Block and Wire Harness (Connector Location)
1A 24 Roof Wire and Driver Side J/B (Lower Finish Panel)
1J 24 Cowl Wire and Driver Side J/B (Lower Finish Panel)
3E 26 Cowl Wire and Center J/B (Near the Steering Column Tube)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IH1 40 Roof Wire and Cowl Wire (Instrument Panel Reinforcement Left)
: GROUND POINTS
Code See Page Ground Points Location
IE 38 Cowl Side Panel LH
IF 38 Cowl Side Panel RH
: SPLICE POINTS
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
B3 42 Roof Wire
2002 4RUNNER (EWD471U)
166
MEMO
2002 4RUNNER (EWD471U)
167
