Image preview - the first page of the document
>> Download camryhv0 documenatation <<
Text preview - extract from the document
G ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
A61 A69 A70 A71 A77 B1 A67 A68 A64 A66 A62
A16
A78
A79
A72
A35
A51
A50
A49
A27
A44
A37
A52
A29 A28 A6 A4 A7 A3 A2 A63 A65 A8 A48 A13 A45 A14 A43 A46 A47
A 2 Ambient Temp. Sensor A 50 Turn Signal and Parking Lamp (Front RH)
A 3 Horn (High) A 51 Side Marker Lamp (Front RH)
A 4 Horn (Low) A 52 Washer Level Warning SW
A 6 A/C Condenser Fan Motor A 61 Hybrid Vehicle Control ECU
A 7 Radiator Fan Motor A 62 Inverter
A 8 Headlamp (LH High) A 63 Current Breaker Sensor
A 13 Airbag Sensor (Front LH) A 64 Water Pump Motor (A/C)
A 14 Speed Sensor (Front LH) A 65 Water Pump Motor (Hybrid Vehicle)
A 16 Brake Fluid Level Warning SW A 66 Power Steering ECU
A 27 A/C Pressure Sensor A 67 Power Steering ECU
A 28 Airbag Sensor (Front RH) A 68 Power Steering ECU
A 29 Headlamp (RH High) A 69 Power Steering Motor
A 35 Speed Sensor (Front RH) A 70 Power Steering Motor
A 37 Windshield Washer Motor A 71 Power Steering Torque Sensor
A 43 Junction Connector A 72 Brake Actuator
A 44 Junction Connector A 77 Brake Stroke Simulator Cylinder
A 45 Headlamp (LH Low) A 78 Short Connector
A 46 Turn Signal and Parking Lamp (Front LH) A 79 Short Connector
A 47 Side Marker Lamp (Front LH)
A 48 Wireless Door Lock Buzzer B 1 Windshield Wiper Motor
A 49 Headlamp (RH Low)
50
CAMRY Hybrid Vehicle (EM02H0U)
G
Position of Parts in Engine Compartment
C9 C30 C8 C12 C10 C14 C5
C6
C64
C2
C32
C15
C7
C31
C11
x1
C13
C58
C22
C61
C20
h1
j1
x2
C63
y2
C16 C23 C4 C62 C59 y1 j2 C60
C 2 Mass Air Flow Meter h 1 Inverter
C 4 Engine Coolant Temp. Sensor
C 5 Throttle Body Assembly j 1 Compressor Motor
C 6 VSV (Purge) j 2 Inverter
C 7 Fuel Injector (No.1)
C 8 Fuel Injector (No.3) x 1 Motor Generator No.1
C 9 Fuel Injector (No.2) x 2 Inverter
C10 Fuel Injector (No.4)
C 11 Ignition Coil (No.1) y 1 Motor Generator No.2
C12 Ignition Coil (No.3) y 2 Inverter
C13 Ignition Coil (No.2)
C14 Ignition Coil (No.4)
C15 Air Fuel Ratio Sensor (Bank 1 Sensor 1)
C16 Noise Filter (Ignition)
C20 Crankshaft Position Sensor
C22 Heated Oxygen Sensor (Bank 1 Sensor 2)
C23 Engine Oil Pressure SW
C30 Knock Control Sensor (Bank 1)
C31 Camshaft Position Sensor
C32 Camshaft Timing Oil Control Valve
C58 Inverter
C59 Motor Generator No.1
C60 Motor Generator No.2
C61 Motor Generator No.2
C62 Park/Neutral Position SW
C63 Compressor Motor
C64 Hybrid Vehicle Control ECU
51
CAMRY Hybrid Vehicle (EM02H0U)
G ELECTRICAL WIRING ROUTING
Position of Parts in Instrument Panel
E7 E6 E1 E14 E12 E11 E10 E27
E5
E8
E9
E13
E3
E2 E21 E16 E18 E17 E20 E19 E30 E29 E35 E34
E 1 Diode (Door Courtesy Rear LH) E 14 Turn Signal Flasher
E 2 Diode (Door Courtesy Rear RH) E 16 Airbag Squib (Steering Wheel Pad)
E 3 Outer Mirror SW E 17 Steering Sensor
E 5 Diode (Door Courtesy Front LH) E 18 Spiral Cable
E 6 Main Body ECU E 19 Windshield Wiper SW Assembly
E 7 Main Body ECU E 20 Windshield Wiper SW Assembly
E 8 Main Body ECU E 21 Headlamp Dimmer SW Assembly
E 9 Main Body ECU E 27 A/C Room Temp. Sensor
E 10 Data Link Connector 3 E 29 Power Outlet Socket (Front)
E 11 Automatic Light Control Sensor E 30 Airbag Sensor Assembly Center
E 12 Ion Generator E 34 Yaw Rate Sensor
E 13 VSC Warning Buzzer E 35 Power Outlet Socket (Rear)
52
CAMRY Hybrid Vehicle (EM02H0U)
G
Position of Parts in Instrument Panel
E40 E50 E46 E62 E63 E43 E44 E45 E38 E70 E71 E37 E41
E61
E58
E60
E39
E67 E66 E51 E42 E52 E69 E54 E48 E49 E55 E68 E57 E56 E72 E53
E 37 Diode (Door Courtesy Front RH) E 54 Airbag Squib (Knee Airbag)
E 38 A/C Amplifier E 55 Seat Heater SW
E 39 Blower Motor E 56 Electrical Key Oscillator (Console)
E 40 Junction Connector E 57 Shift Lock Control ECU
E 41 Junction Connector E 58 Certification ECU
E 42 Junction Connector E 60 Tire Pressure Warning ECU
E 43 Junction Connector E 61 Option Connector (Bus Buffer)
E 44 Junction Connector E 62 Junction Connector
E 45 Junction Connector E 63 Junction Connector
E 46 Junction Connector E 66 ECO SW
E 48 Junction Connector E 67 Fuel Lid Opener SW
E 49 Junction Connector E 68 PTC Heater
E 50 ID Code Box E 69 Junction Connector
E 51 Steering Lock ECU E 70 Short Connector
E 52 Power SW E 71 Short Connector
E 53 Tire Pressure Warning Reset SW E 72 A/T Shift Lever Illumination
53
CAMRY Hybrid Vehicle (EM02H0U)
G ELECTRICAL WIRING ROUTING
Position of Parts in Instrument Panel
(*1) (*2)
F21 F2 F1 F3 F14 F4 F11 F8 F9 F26 F23 F25 F5
F12
F15
F16
* 1:w/ Navigation System
* 2:w/o Navigation System
F10 F13 F17 F20 F18 F19
F 1 Combination Meter F 14 Navigation Receiver Assembly
F 2 Combination Meter F 15 Antenna Amplifier
F 3 Clock F 16 A/C Control Assembly
F 4 Hazard Warning Signal SW F 17 Stereo Jack Adapter
F 5 Glove Box Lamp F 18 Stereo Component Amplifier
F 8 Radio Receiver Assembly F 19 Stereo Component Amplifier
F 9 Navigation Receiver Assembly F 20 Stereo Component Amplifier
F 10 Navigation Receiver Assembly F 21 Tweeter (Front LH)
F 11 Radio Receiver Assembly F 23 Tweeter (Front RH)
F 12 Navigation Receiver Assembly F 25 Junction Connector
F 13 Navigation Receiver Assembly F 26 Radio Receiver Assembly
54
CAMRY Hybrid Vehicle (EM02H0U)
G
Position of Parts in Instrument Panel
A18 A58 a1 b1 c2 c1
A80 A19 A41 A42 A17 N1 O1 e1 A73 A74 A75 A76 A40
A 17 Accelerator Position Sensor O 1 Airbag Sensor Assembly Center
A 18 Parking Brake SW
A 19 Stop Lamp SW a 1 Spiral Cable
A 40 Junction Connector Steering Pad SW
A 41 Junction Connector
A 42 Junction Connector b 1 Cruise Control SW
A 58 Junction Connector Spiral Cable
A 73 Skid Control ECU
A 74 Skid Control ECU c 1 Airbag Squib (Front Passenger's Airbag Assembly)
A 75 Skid Control ECU c 2 Airbag Squib (Front Passenger's Airbag Assembly)
A 76 Skid Control ECU
A 80 Brake Pedal Stroke Sensor e 1 A/C Amplifier
A/C Blower Assembly
N 1 Airbag Sensor Assembly Center
55
CAMRY Hybrid Vehicle (EM02H0U)
G ELECTRICAL WIRING ROUTING
Position of Parts in Body
N18 N29 O16 N19 O6 O7
O8
O18
P1
N21
O14
N20
O21
N6
O10
N7
O19
O15
O24
O25
O23
N8 N13 N15 N12 N37 N16 N36 N35 N10 N28 N23 N11 N17 N38 N25 N24 O9
N 6 Door Courtesy SW (Driver's Side) O 6 Door Courtesy SW (Front Passenger's Side)
N 7 Side Airbag Sensor (Front LH) O 7 Side Airbag Sensor (Front RH)
N 8 Pretensioner (LH) O 8 Pretensioner (RH)
N10 Fuel Suction Pump and Gage Assembly O 9 Side Airbag Sensor (Rear RH)
N 11 Electrical Key Oscillator (Rear Seat) O10 Door Courtesy SW (Rear RH)
N12 Side Airbag Sensor (Rear LH) O14 Speaker (Rear LH)
N13 Door Courtesy SW (Rear LH) O15 Speaker (Rear RH)
N15 Noise Filter (Dome and Stop) O16 Curtain Shield Airbag Squib (RH)
N16 Center Stop Lamp O18 Door Control Receiver
N17 Canister Pump Module O19 Electrical Key Antenna
N18 Noise Filter (Rear Window Defogger) O21 Junction Connector
N19 Rear Window Defogger O23 Brake Control Power Supply Assembly
N20 Tire Pressure Warning Antenna and Receiver O24 Battery Thermometer Sensor
N21 Curtain Shield Airbag Squib (LH) O25 Fusible Link Block
N23 Diode (Luggage Compartment Lamp)
N24 Luggage Compartment Lamp P 1 Rear Window Defogger
N25 Electrical Key Oscillator (Inside Luggage Room)
N28 Junction Connector
N29 Junction Connector
N35 Vapor Pressure Sensor
N36 Fuel Lid Opener Motor
N37 Fuel Lid Courtesy SW
N38 Battery Blower Motor
56
CAMRY Hybrid Vehicle (EM02H0U)
G
Position of Parts in Body
Q7 Q5 Q12 Q3 Q6 Q9 H2 Q8 Q2 H4 H5 H6 Q11 Q10 W2 H8 H7 J1
Q1
J3
H1
J5
W1
S11
I3
S9
I1
f1
I4
S4
M1
S12
X1
S2
X2
S1
I6 I7 K1 K3 K5 g1 S15 S16 S3 k1 S14 S5 S6
H 1 Speaker (Front Door RH) Q 8 Vanity Lamp (RH)
H 2 Outer Rear View Mirror (RH) Q 9 Room Lamp (Center)
H 4 Power Window Regulator Motor Q10 Map Lamp (RH)
(Front Passenger's Side) Q11 Map Lamp (LH)
H 5 Door Lock Control SW Q12 Sliding Roof Control ECU and Motor
H 6 Power Window SW (Front Passenger's Side)
H 7 Courtesy Lamp (Front Door RH) S 1 License Plate Lamp (RH)
H 8 Door Lock Assembly (Front Passenger's Side) S 2 Back◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
