Image preview - the first page of the document
>> Download cautionl documenatation <<
Text preview - extract from the document
BODY PANEL REPLACEMENT BP-75
CAUTION LABEL ATTACHMENT POSITION
After using a degreasing agent to clean the surfaces of the body where the caution labels will be attached, attach the
caution labels to the positions shown in the illustration.
HINT:
1) Attach each caution label with its orientation the same as the numbers shown in the illustration.
2) Make sure the caution label is not attached over a spot weld.
3) When attaching the caution label, make sure not to touch the label's adhesive surface.
4) To prevent the edges of the caution label from peeling, apply extra pressure to the label's periphery.
5) If the work area's temperature is 5_C or less, the caution label's adhesive will deteriorate. It is
recommended that you heat the label to 20 to 40_C.
Loaded Inspection Maintenance Exemption (VSC only)
Emission Control Information
Long Life Coolant Service Label
Engine Vacuume Hose Information
Battery Caution
Cooler Service Caution
F26007
BP-76 BODY PANEL REPLACEMENT
Fuel Label
Certification Reguration Information Label
Tire Pressure
Label Information
Side Air Bag Caution Label
Mercury Information Label
Side Air Bag Caution Label
F26008
