BP-18                                     BODY PANEL REPLACEMENT


                            COWL TOP OUTER PANEL (ASSY)
                                     With the cowl top side reinforcement and front body pillar lower gusset removed.



                                        Symbol meaning

                                          REMOVAL              : Remove Weld Points       : Cut with disc sander, etc.
                                          INSTALLATION         : MIG Plug Weld            : Tack Weld
                           F25721A                                                                                   F25721B

 REMOVAL.INSTALLATION




                                                            7
                                                          (0.28)




                                                                                                               mm (in.)
                                                                                                                         F25721

 INSTALLATION POINT
 1   Temporarily install the new parts and measure each part of the new parts in accordance with the body
     dimension diagram. (See the body dimension diagram)
 2   After welding, apply body sealer to the corresponding parts. (See the paint.coating)
 3   After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
     weld points.
