Image preview - the first page of the document
>> Download cowltops documenatation <<
Text preview - extract from the document
BP-16 BODY PANEL REPLACEMENT
COWL TOP SIDE REINFORCEMENT (ASSY)
Symbol meaning
REMOVAL : Cut with disc sander, etc.
INSTALLATION : Tack Weld
F25720A F25720B
REMOVAL.INSTALLATION
13
(0.51)
15
(0.59) 15
(0.59)
10 25
(0.39) (0.98) mm (in.)
F25720
INSTALLATION POINT
1 After welding, apply body sealer to the corresponding parts. (See the paint.coating)
2 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
