Image preview - the first page of the document
>> Download frontcro documenatation <<
Text preview - extract from the document
BP-4 BODY PANEL REPLACEMENT
FRONT CROSSMEMBER (ASSY)
Symbol meaning
REMOVAL : Remove Weld Points : Cut with disc sander, etc.
INSTALLATION : MIG Plug Weld : Tack Weld
F25705A F25705B
REMOVAL.INSTALLATION
10
(0.39)
mm (in.)
F25705
INSTALLATION POINT
1 Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
finish.
2 Temporarily install the new parts and measure each part of the new parts in accordance with the body
dimension diagram. (See the body dimension diagram)
3 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
