BP-6 BODY PANEL REPLACEMENT
FRONT FENDER FRONT APRON (ASSY)
With the radiator support removed.
Symbol meaning
REMOVAL : Remove Weld Points : Cut with disc sander, etc.
INSTALLATION : MIG Plug Weld : Tack Weld
F25707A F25707B
REMOVAL.INSTALLATION
F25707
INSTALLATION POINT
1 Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
finish.
2 Temporarily install the new parts and measure each part of the new parts in accordance with the body
dimension diagram. (See the body dimension diagram)
BODY PANEL REPLACEMENT BP-7
Fender Apron Plate
LH:
RH:
6
(0.24)
Front Fender Apron Front Extension
15
(0.59)
6
(0.24)
mm (in.)
F25708
REMOVAL POINT
1 Remove the front fender apron front extension at the same time.
INSTALLATION POINT
1 Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
finish.
2 Temporarily install the new parts and measure each part of the new parts in accordance with the body
dimension diagram. (See the body dimension diagram)
3 After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
4 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
