Image preview - the first page of the document
>> Download frontsid documenatation <<
Text preview - extract from the document
BP-14 BODY PANEL REPLACEMENT
FRONT SIDE MEMBER (CUT-H)
With the front fender apron removed.
Symbol meaning
: Remove Weld Points
F25714A F25714B
REMOVAL
F25714
BODY PANEL REPLACEMENT BP-15
Symbol meaning
: MIG Plug Weld
F25715B
INSTALLATION
Front Side Member Extension
CAUTION
Make sure to attach correctry in accordance with the body dimention diagram as this parts affects
the front wheel alignment.
F25715
INSTALLATION POINT
1 Temporarily install the new parts and measure each part of the new parts in accordance with the body
dimension diagram. (See the body dimension diagram)
2 After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
3 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
