                                        BODY PANEL REPLACEMENT                                                BP-73


                    NAME PLATE APPLICATION PROCEDURE
(a)   Heat the double-sided tape remaining on the body with an infrared lamp or equivalent.
      HINT:
      Heat the tape to 40 to 60_C for approximately 1 to 2 minutes.
(b)   Wipe off the remaining double-sided tape using a clean cloth or equivalent.
      HINT:
      If a name plate is installed without thoroughly removing the remaining double-sided tape from the body, the
      name plate will not adhere properly. Make sure to thoroughly wipe off the double-sided tape.
(c)   After cleaning the installation area of the body with degreasing agent, attach the name plate to the position
      shown in the illustration.
      HINT:
      The working environment should be 20_C when installing the name plate. If the working environment is below
      20_C, heat the installation area of the body to 20 to 30_C and then install the name plate.




                                                              16.0
                                                            (0.630)


                                                                                                           8.1
                                                                                                         (0.319)

                                                                5.5
                                                              (0.217)




                                                              72.7                                            72.1
                                                            (2.862)                                         (2.839)




                                                                                              88.3
                                                                                            (3.476)

                                                                               159.8
                                                                              (6.291)




                                                                                                          mm (in.)
                                                                                                                F26010
BP-74   BODY PANEL REPLACEMENT




                  130.3                               122.0
                 (5.130)                             (4.803)




                                            115.4
                                           (4.543)
                               262.7
                             (10.342)




                121.8                                 130.2
               (4.795)                               (5.126)



                            114.1
                           (4.492)

                                          260.8
                                        (10.268)




                                                      mm (in.)
                                                               F25810
