Image preview - the first page of the document
>> Download quarterw documenatation <<
Text preview - extract from the document
BODY PANEL REPLACEMENT BP-41
QUARTER WHEEL HOUSING OUTER PANEL (ASSY)
With the quarter panel removed.
Symbol meaning : Cut with disc sander, etc.
: Remove Weld Points : Cut and Join Location
REMOVAL
INSTALLATION : MIG Plug Weld : Tack Weld : Butt Weld
F25739A F25739B
REMOVAL.INSTALLATION
[LH]
310
(12.20)
Rocker Outer Extension
mm (in.)
F25739
REMOVAL POINT
1 *1: Take care not to damage the internal reinforcement.
2 After removing the rocker outer extension, remove the quarter wheel housing outer panel.
INSTALLATION POINT
1 After welding the quarter wheel housing outer panel to the vehicle side, install the rocker outer extension.
BP-42 BODY PANEL REPLACEMENT
Symbol meaning : Cut with disc sander, etc.
: Remove Weld Points : Cut and Join Location
REMOVAL
INSTALLATION : MIG Plug Weld : Tack Weld : Butt Weld
F25739B
[LH]
Roof Side Outer Panel
F25740
REMOVAL POINT
1 After removing the roof side outer panel, remove the quarter wheel housing outer panel.
INSTALLATION POINT
1 After welding the quarter wheel housing outer panel to the vehicle side, install the roof side outer panel.
BODY PANEL REPLACEMENT BP-43
[LH]
20
(0.79)
mm (in.)
F25742
INSTALLATION POINT
1 After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
2 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
BP-44 BODY PANEL REPLACEMENT
Symbol meaning : Cut with disc sander, etc.
: Remove Weld Points : Cut and Join Location
REMOVAL
INSTALLATION : MIG Plug Weld : Tack Weld : Butt Weld
F25739B
[RH]
310
(12.20)
Rocker Outer Extension
mm (in.)
F25795
REMOVAL POINT
1 *1: Take care not to damage the internal reinforcement.
2 After removing the rocker outer extension, remove the quarter wheel housing outer panel.
INSTALLATION POINT
1 After welding the quarter wheel housing outer panel to the vehicle side, install the rocker outer extension.
BODY PANEL REPLACEMENT BP-45
[RH]
Roof Side Outer Panel
F25741
REMOVAL POINT
1 After removing the roof side outer panel, remove the quarter wheel housing outer panel.
INSTALLATION POINT
1 After welding the quarter wheel housing outer panel to the vehicle side, install the roof side outer panel.
BP-46 BODY PANEL REPLACEMENT
Symbol meaning : Cut with disc sander, etc.
: Remove Weld Points : Cut and Join Location
REMOVAL
INSTALLATION : MIG Plug Weld : Tack Weld : Butt Weld
F25739B
[RH]
20
(0.79)
mm (in.)
F25796
INSTALLATION POINT
1 After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
2 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
