Image preview - the first page of the document
>> Download radia documenatation <<
Text preview - extract from the document
BP-2 BODY PANEL REPLACEMENT
RADIATOR SUPPORT UPPER BRACE (ASSY)
With the radiator upper support removed.
Symbol meaning
REMOVAL : Remove Weld Points
INSTALLATION : MIG Plug Weld
F25702A F25702B
REMOVAL.INSTALLATION
Front Bumper Upper Arm
Radiator
Support
F25702
REMOVAL POINT
1 Remove the radiator support at the same time.
INSTALLATION POINT
1 Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
finish.
2 Temporarily install the new parts and measure each part of the new parts in accordance with the body
dimension diagram. (See the body dimension diagram)
3 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
BODY PANEL REPLACEMENT BP-3
522
(20.55)
1,482
(58.35)
1,218
(47.95) 1,462
(57.56)
872
(34.33) 456
(17.95)
978
(38.50)
mm (in.)
F25704
INSTALLATION POINT
1 Measure the dimensions before installing the headlights.
2 These values are reference values.
