Image preview - the first page of the document
>> Download rearf0 documenatation <<
Text preview - extract from the document
BODY PANEL REPLACEMENT BP-55
REAR FLOOR SIDE PANEL (ASSY)
With the rear floor pan removed.
Symbol meaning
REMOVAL : Remove Weld Points
INSTALLATION : MIG Plug Weld
F25750A F25750B
REMOVAL.INSTALLATION
[LH]
F25750
INSTALLATION POINT
1 After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
2 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
BP-56 BODY PANEL REPLACEMENT
Symbol meaning
REMOVAL : Remove Weld Points
INSTALLATION : MIG Plug Weld
F25750B
[RH]
F25751
INSTALLATION POINT
1 After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
2 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
