Image preview - the first page of the document
>> Download rearfloo documenatation <<
Text preview - extract from the document
BODY PANEL REPLACEMENT BP-49
REAR FLOOR NO. 3 CROSSMEMBER (ASSY)
With the body lower back panel removed.
Symbol meaning
REMOVAL : Remove Weld Points
INSTALLATION : Spot Weld : MIG Plug Weld
F25746A F25746B
REMOVAL.INSTALLATION
F25746
INSTALLATION POINT
1 Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
finish.
2 After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
3 After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
weld points.
