                                         BODY PANEL REPLACEMENT                                                 BP-61


                               ROOF PANEL (ASSY): Moon Roof


                                     Symbol meaning

                                      REMOVAL               : Remove Weld Points
                                      INSTALLATION          : Spot Weld       : MIG Plug Weld        : Body Sealer


                           F25755A                                                                              F25755B

REMOVAL.INSTALLATION




                                                                                   Cloth Tape

                                                         Wooden Hammer




     Disc Sander

                   [Removal]
                                                                                     [Install]

                                                                                                                 F25755

INSTALLATION POINT
1   Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
    finish
2   Temporarily install the new parts and measure each part of the new parts in accordance with the body
    dimension diagram. (See the body dimension diagram)
3   After welding, apply body sealer to the corresponding parts. (See the paint.coating)
4   After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
    weld points.
BP-62                                  BODY PANEL REPLACEMENT




   Symbol meaning

        REMOVAL          : Remove Weld Points
        INSTALLATION     : Spot Weld      : MIG Plug Weld      : Body Sealer
                                                                                                          F25755B




                                                                                                           F25756

 INSTALLATION POINT
 1   Before temporarily installing the new parts, apply body sealer to the windshield header panel, roof panel
     reinforcement and back door opening frame.
     HINT:
     1) Apply just enough sealer for the new parts to make contact.
