Image preview - the first page of the document



>> Download rocke documenatation <<

Text preview - extract from the document

BP-34                                      BODY PANEL REPLACEMENT


                          ROCKER OUTER EXTENSION (ASSY)


                                     Symbol meaning

                                        : Remove Weld Points      : Cut and Join Location   : Cut Location for Supply Parts



                          F25731A                                                                                   F25731B

 REMOVAL




                   Center Body Outer Pillar

                                  280
                                (11.02)




                                                             Quarter Panel




                  260
                (10.24)




                70
              (2.76)




                                    Center Body Pillar Lower Reinforce




                                                                                                               mm (in.)
                                                                                                                     F25731

 REMOVAL POINT
 1  *1 in illustration above indicates where the adhesive is.
 2  After removing the center body outer pillar and quarter panel, remove the rocker outer extension and center
    body pillar lower reinforce.
                                            BODY PANEL REPLACEMENT                                              BP-35




   Symbol meaning

       : MIG Plug Weld        : Butt Weld         : Body Sealer

                                                                                                                F25732B

INSTALLATION


                                            Rocker Panel Reinforcement




                           Center Body Pillar Lower Reinforce

                Center Body Outer Pillar




                                                      Quarter Panel



                                                                                                                 F25732

INSTALLATION POINT
1   Inspect the fitting of the related parts around the new parts before welding. This affects the appearance of the
    finish.
2   Temporarily install the new parts and measure each part of the new parts in accordance with the body
    dimension diagram. (See the body dimension diagram)
3   Before temporarily installing the new parts, weld the rocker panel reinforcement and rocker outer extension
    with the standard number of welding points.
4   Before installing a new part, apply body sealer.
    HINT:
    1) Apply sealer in an even, continuous bead.
5   After welding the center body pillar lower reinforce and rocker outer extension to the vehicle side, install the
    center body outer pillar and quarter panel.
6   After welding, apply body sealer and undercoating to the corresponding parts. (See the paint.coating)
7   After applying the top coat, apply anti-rust agent to the internal panel portion of the closed section structural
    weld points.
