IN-24                        INTRODUCTION


NOTICE ABOUT VEHICLE CONDITION WHEN JACKING UP VEHICLE
1.   NOTICE FOR USING JACK AND SAFETY STAND




        Front




                                            : JACK POSITION



                                            : SUPPORT POSITION,
                                              PANTOGRAPH JACK POSITION


                                            : CENTER OF VEHICLE GRAVITY
                                              (unloaded condition)




                                                                          D100366
                                                        INTRODUCTION                                                                 IN-25

2.   NOTICE FOR USING SWING ARM TYPE LIFT

                                                                 Center of Lift




                                CENTER OF VEHICLE
                                GRAVITY
                                (unloaded condition)
                                                                                                      Rubber Attachment




                                                                                                                                  D100367




3.   NOTICE FOR USING PLATE TYPE LIFT




                                                                                           Attachment Dimensions

                                                                                                 85 mm (3.35 in.)

                                                                                                                     70 mm
                                              Attachment                                                             (2.76 in.)

                                                                                  100 mm (3.94 in.)
                                                                                                      200 mm (7.87 in.)

     HINT:
     Right and left set position
      Place the vehicle over the center of the lift.                                                                        mm (in.)
     HINT:
     Front and left set position
      Place the attachments at the ends of the rubber plate surface, under the vehicle lift pad (A and C in the illustration).
      Raise the plate slightly and reposition the vehicle so the top of the attachment (B in the illustration) is aligned with the
      front side notch in the vehicle rocker flange.
                                                                                                                                     F30268
