Image preview - the first page of the document
>> Download bodypane documenatation <<
Text preview - extract from the document
PAINT S COATING PC-1
BODY PANEL SEALING AREAS
Be sure to apply body sealer to the body panel joints and door edges (tip of outer panel folded part), etc., to water-
proof and rustproof them.
HINT:
1) Apply degreasing agent to a clean cloth and clean the sealer application areas.
2) After removing the applied spot sealer from the sealer application areas using thinner or equivalent, rustproof
the areas by applying primer or equivalent. Then apply body sealer.
3) If sealer is unnecessarily applied to an area, apply degreasing agent to a clean cloth and clean off the sealer
immediately.
Flat Finishing No Flat Finishing
1. ENGINE COMPARTMENT
F25781
PC-2 PAINT S COATING
2. INSIDE
F26006
PAINT S COATING PC-3
3. OUTSIDE
F25783
PC-4 PAINT S COATING
F26013
PAINT S COATING PC-5
4. DOOR PARTS
F26014
PC-6 PAINT S COATING
F26015
