Image preview - the first page of the document
>> Download electrical component locator documenatation <<
Text preview - extract from the document
ELECTRICAL COMPONENT LOCATOR
1988 Toyota Celica
1988 TOYOTA
Celica Electrical Components
----------------------------------------------------------------------
BUZZERS, RELAYS & TIMERS
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
Automatic Antenna Relay Left rear fender, near
automatic antenna.
A/C Fan Relay No. 1
(3S-GE) On fuse/relay block No. 2, on
front left inner fender.
(3S-FE & 3S-GTE) On fuse/relay block No. 2, on
front left inner fender.
A/C Fan Relay No. 2 On fuse/relay block No. 5, on
left side of radiator.
A/C Fan Relay No. 3 On fuse/relay block No. 5, on
left side of radiator.
A/C Clutch Relay On fuse/relay block No. 5, on
left side of radiator.
Anti-Lock Brake System (ABS) Relay
2WD ABS Location (Graphic 1) Near left strut tower.
2WD ABS Location (Graphic 2) Near left strut tower.
4WD Under case cover on actuator.
Blower Speed Relay
(Graphic No. 1) Behind right side of dash, on
evaporator housing.
Blower Speed Relay
(Graphic No. 2) Behind right side of dash, on
evaporator housing.
Circuit Opening Relay On center of dash, near ECU.
Clutch Starter Relay On fuse/relay block No. 1,
behind left kick panel.
Defogger Relay On fuse/relay block No. 1,
behind left kick panel.
Door Lock Control Relay Inside driver's door, behind
door panel.
Fog Light Relay Above glove box.
Fuel Pump Relay (3S-GTE)
(Graphic 1) Center of firewall.
Fuel Pump Relay (3S-GTE)
(Graphic 2) Center of firewall.
EFI Main Relay (3S-GE) On fuse/relay block No. 2, on
front left inner fender.
EFI Main Relay (3S-FE & 3S GTE) On fuse/relay block No. 2, on
front left inner fender.
Engine Main Relay (3S-GE)
(Graphic 1) On fuse/relay block No. 2, on
front left inner fender.
Engine Main Relay (3S-FE &
3S GTE) (Graphic 2) On fuse/relay block No. 2, on
front left inner fender.
Headlight Control Relay (3S-GE)
(Graphic 1) On fuse/relay block No. 2, on
front left inner fender.
Headlight Control Relay (3S-FE
& 3S GTE) (Graphic 2) On fuse/relay block No. 2, on
front left inner fender.
Heater Relay On fuse/relay block No. 4,
behind right kick panel.
Horn Relay On fuse/relay block No. 4,
behind right kick panel.
Ignition Key Light, Seat Belt &
Key Warning Buzzer Relay On back side of fuse/relay
block No. 1.
Light Retractor Relay Behind center dash console.
Rear Wiper Relay Inside liftgate, near rear
window wiper motor.
Sun Roof Control Relay In front of sun roof opening.
Taillight Control Relay On fuse/relay block No. 1,
behind left kick panel.
Turn Signal/Hazard Flasher
(Graphic 1) On fuse/relay block No. 1,
behind left kick panel.
Turn Signal/Hazard Flasher
(Graphic 2) On fuse/relay block No. 1,
behind left kick panel.
----------------------------------------------------------------------
CIRCUIT PROTECTION DEVICES
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
A/C Fuse On fuse/relay block No. 4,
behind right kick panel.
Circuit Breakers
Door Lock On fuse/relay block No. 1,
behind left kick panel.
Heater On fuse/relay block No. 4,
behind right kick panel.
Power Window On fuse/relay block No. 1,
behind left kick panel.
Window Defogger On fuse/relay block No. 1,
behind left kick panel.
Fuse/Relay Block No. 1
(Graphic 1) Behind left kick panel.
Fuse/Relay Block No. 1
(Graphic 2) Behind left kick panel.
Fuse/Relay Block No. 2
(Graphic 1) On front left inner fender.
Fuse/Relay Block No. 2
(Graphic 2) On front left inner fender.
Fuse/Relay Block No. 2 (3S-GE) On front left inner fender.
Fuse/Relay Block No. 2
(3S-FE & 3S-GTE) On front left inner fender.
Fuse/Relay Block No. 4
(Graphic 1) Behind right kick panel.
Fuse/Relay Block No. 4
(Graphic 2) Behind right kick panel.
Fuse/Relay Block No. 5 W/ABS
(Graphic 1) On right front side of engine
compartment.
Fuse/Relay Block No. 5 W/ABS
(Graphic 2) On right front side of engine
compartment.
Fuse/Relay Block No. 5 W/O ABS
& 4WD (Graphic 1) On left front side of engine
compartment.
Fuse/Relay Block No. 5 W/O ABS
& 4WD (Graphic 2) On left front side of engine
compartment.
----------------------------------------------------------------------
CONTROL UNITS
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
Anti-Lock Brake System (ABS)
Computer 2WD Models (Graphic 1) Under center of dash, above
electronic control unit.
Anti-Lock Brake System (ABS)
Computer 2WD Models (Graphic 2) Under center of dash, above
electronic control unit.
Anti-Lock Brake System (ABS)
Computer 4WD Models Behind rear seat.
Cruise Control Computer Behind right kick panel, above
fuse/relay block No. 4.
Electronic Controlled
Transmission (ECT) Computer Under center console, near
shift lever.
Electronic Control Unit (ECU) Under center of dash.
Intercooler Computer (3S-GTE) Under right side of dash.
----------------------------------------------------------------------
MOTORS
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
A/C Power Servo Under center of dash, on A/C
unit.
Air Mix Control Motor Under center of dash, on A/C
unit.
Air Vent Mode Control Motor Under center of dash, on A/C
unit.
Blower Motor On bottom of blower motor
housing.
Fuel Pump Motor In fuel tank.
Headlight Retract Motors On radiator side of each
headlight.
Recirculating/Fresh
Control Servo Under center of dash, on A/C
unit.
Window Washer Motor On right front corner of
engine compartment.
Windshield Wiper Motor On right rear corner of engine
compartment.
----------------------------------------------------------------------
SENDING UNITS & SENSORS
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
ABS Speed Sensor One in each wheel hub.
A/T Speed Sensors The No. 1 is on speedometer
and No. 2 on rear of
transaxle.
Auto. A/C Ambient Temp. Sensor On front grille of vehicle,
near hood latch.
Auto. A/C In-Car temp. Sensor Behind center of dash.
Auto. A/C Solar Sensor On top of right side of dash.
Coolant Temperature Sensor
(3S-FE) (Graphic 1) On coolant outlet flange.
Coolant Temperature Sensor
(3S-FE) (Graphic 2) On coolant outlet flange.
Coolant Temperature Sensor
(3S-GE) (Graphic 1) On rear of engine, on coolant
outlet flange.
Coolant Temperature Sensor
(3S-GE) Graphic 2 On rear of engine, on coolant
outlet flange.
Coolant Temperature Sensor
(3S-GTE) On rear of engine, on coolant
outlet flange.
Coolant Level Sensor (3S-GTE) Mounted on top of intercooler.
Deceleration Sensor (4WD) Behind rear seat, near ABS
computer.
EGR Gas Temp. Sensor (Calif.) Mounted on side of EGR valve.
Knock Sensor (3S-GTE) On intake side of cylinder
block, near No. 1 cylinder.
Oil Pressure Sending Unit
(3S-GE & 3S-GTE) On left side of engine.
Oil Pressure Sending Unit
(3S-FE) On left side of engine.
Oxygen Sensor (3S-GE) In exhaust manifold.
Oxygen Sensor (3S-FE) In exhaust manifold.
Oxygen Sensor (3S-GTE) In exhaust manifold.
Taillight Failure Sensor Above rear left wheelwell.
Throttle Position Sensor On throttle body housing.
Turbo Pressure Sensor (3S-GTE) On left rear corner of engine
compartment.
----------------------------------------------------------------------
SOLENOIDS & SOLENOID VALVES
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
A/C Idle-Up VSV On firewall, near windshield
wiper motor.
A/T No. 1 & No. 2 Solenoids On transaxle valve body.A/T
Lock-Up Solenoid On transaxle case, near oil
filler tube.
Door Lock Solenoid Inside door, behind door
panel.
EGR VSV (3S-GTE) In front of EGR vacuum
modulator.
Fuel Pressure VSV (3S-GTE) On lower side of intake
manifold.
Turbo Pressure VSV On lower side of intake
manifold.
VIS VSV (3S-GTE) On lower side of intake
manifold.
----------------------------------------------------------------------
SWITCHES
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
A/C Pressure Switches On A/C line, in right rear
corner of engine compartment.
Auto. A/C Coolant Temp. Switch Under heater core.
Back-Up Light Switch (M/T) On top of transaxle.
Brake Fluid Level
Warning Switch On bottom of brake fluid
reservoir cap.
Cold Start Injector Time Switch
(3E-FE) (Graphic 1) On rear of engine, on coolant
outlet.
Cold Start Injector Time Switch
(3E-FE) (Graphic 2) On rear of engine, on coolant
outlet.
Cold Start Injector Time Switch
(3E-GE) On rear of engine, on coolant
outlet.
Cold Start Injector Time Switch
(3E-GTE) On rear of engine, on coolant
outlet.
Cruise Control Brake Switch On brake pedal bracket.
Cruise Control Clutch Switch (M/T) On clutch pedal bracket.
ECT Pattern Select Switch At base of shift lever.
Neutral Start Switch (A/T) On left edge of transaxle.
Parking Brake Switch At base of parking brake
lever.
Seat Belt Buckle Switch At base of seat belt buckle.
Stoplight Switch On brake pedal bracket.
Sun Roof Limit Switches In sun roof rail, near sun
roof motor.
Unlock Warning Switch On steering column, next to
ignition switch.
Vacuum Switch (W/ABS) Left front corner of engine
compartment.
----------------------------------------------------------------------
MISCELLANEOUS
----------------------------------------------------------------------
Component Component Location
----------------------------------------------------------------------
ABS Actuator On right front fender inner
panel.
A/C Amplifier No. 1 (Graphic 1) Behind glove box, attached to
bottom of evaporator housing.
A/C Amplifier No. 1 (Graphic 2) Behind glove box, attached to
bottom of evaporator housing.
A/C Amplifier No. 1 (Graphic 1) Behind center of dash,
attached to front of heater
unit.
A/C Amplifier No. 1 (Graphic 2) Behind center of dash,
attached to front of heater
unit.
A/C Power Servo Behind center of dash, under
heater unit.
Cruise Control Actuator On right front inner fender,
in front of right shock tower.
Diagnostic Test Connector Behind front left shock tower.
Fuel Pump Resistor (3S-GTE) Left corner of engine
compartment.
Intercooler Coolant Pump (3S-GTE) In the line from intercooler
radiator to intercooler.
Solenoid Resistor (3S-GTE) Center of firewall.
Vacuum Pump (W/ABS) Left front corner of engine
compartment.
----------------------------------------------------------------------
