Image preview - the first page of the document



>> Download starter reduction gear documenatation <<

Text preview - extract from the document

                              STARTER - REDUCTION GEAR

                                      1988 Toyota Celica




         1988 Starters
         MITSUBA & NIPPONDENSO REDUCTION GEAR

        Toyota Camry, Celica, Corolla, Cressida,
        Land Cruiser, Pickup, MR2, Supra, Van, 4Runner

    DESCRIPTION
         Mitsuba and Nippondenso starters are 12-volt, 4-brush,
solenoid-actuated, gear reduction-type, equipped with an overrunning
clutch. The brush holder assembly retains brushes and springs in the
starter housing.

    TESTING

    PERFORMANCE TESTS
         No Load Test
         1) Remove starter. Connect ammeter in series with starter
motor and 12-volt battery. See Fig. 1. Connect voltmeter in parallel
with battery and observe readings.
         2) Starter should spin smoothly at 3000 RPM or more with
current draw less than 90 amps at 11.5 volts.




Fig. 1: Ammeter & Voltmeter Hook-Up for No Load Test
Courtesy of Subaru of America, Inc.

    COMPONENT TESTING
         Brushes & Springs
         1) Check brush length. If less than specification, replace
brushes. See MINIMUM BRUSH LENGTH SPECIFICATIONS table.
         2) Check condition of brush holders, springs, spring clip and
insulation between positive and negative holders and repair or replace
as needed.

MINIMUM BRUSH LENGTH SPECIFICATIONS
