Image preview - the first page of the document
>> Download FUSES_AN documenatation <<
Text preview - extract from the document
FUSES & CIRCUIT BREAKERS
1993 Toyota Celica
FUSES & CIRCUIT BREAKERS
1983-93 Toyota
Celica
IDENTIFICATION
FUSE PANEL LOCATION (1983-85)
There are 3 fuse panels on this vehicle. The driver's side
fuse box is located behind the driver's kick panel. The passenger's
side fuse box is behind the passenger's side kick panel. The main fuse
and relay block is in the engine compartment.
PASSENGER COMPARTMENT FUSE BOX IDENTIFICATION (1983-85)
Fig. 1: Passenger Compartment Fuse Boxes Identification
Courtesy of Toyota Motor Sales, U.S.A., Inc.
* 1 - 7.5 Amp
Gauges & Warning Lights/Indicators, A/T Overdrive System &
Back-Up Lights, Main Heater Relay Coil (1983)
* 2 - 7.5 Amp
Radio & Cassette Player
* 3 - 15 Amp
Trip Computer (Supra)
* 4 - 7.5 Amp
Retractable Headlight System (1983-84), Outside Mirror
Defogger (1985 Supra)
* 5 - 7.5 Amp
Discharge Warning Light, Main Ignition Relay Coil, Main EFI
Relay (1983 Supra)
* 6 - 7.5 Amp
Interior, Personal & Door Courtesy Lights, Trunk, Ignition
Switch & Door Warning Lights, Clock & Power Antenna
(1984-85), Vanity Lights (Supra)
* 7 - 15 Amp
Cigarette Lighter & Outside Mirror, Clock (1983), Trip
Computer (1983 Supra)
* 8 - 15 Amp
Cruise Control System, Electronically Controlled A/T System
(1984-85 Supra)
* 9 - 7.5 Amp
Turn Signal Lights
* 10 - 15 Amp
Foglights (Supra)
* 11 - 10 Amp
Air Conditioner
* 12 - Blank
ENGINE COMPARTMENT MAIN BLOCK IDENTIFICATION (1983-85)
Fig. 2: Engine Compartment Main Fuse & Relay Block Identification
Courtesy of Toyota Motor Sales, U.S.A., Inc.
* 1 - Blank
* 2 - 7.5 Amp
Discharge Warning Light
* 3 - 15 Amp
Alternator With IC Regulator, Emission Control System
(1984-85)
* 4 - 15 Amp
Hazard Lights & Horns, Radio (1983), Retractable Headlights
(1985)
* 5 - 15 Amp
A/T Shift Position Indicator Light, Clock (Digital), Side
Marker & License Lights, Park Lights, Taillights & Glove Box
Light, Instrument Panel Lights, Foglight Relay (1983 Supra)
* 6 - 15 Amp
Right Headlight, High Beam Indicator Light (1983)
* 7 - 15 Amp
Left Headlight
* 8 - Blank
* 9 - 15 Amp
EFI Control System
* 10 - 20 Amp
Wipers & Washers, Headlight Cleaner Relay (1984-85 Supra)
* 11 - 15 Amp
Stoplights, Cruise Control System (1983 Supra)
* 12 - Blank
* 13 - 15 Amp
Right Low Beam Headlight (1983)
* 14 - 15 Amp
Left Low Beam Headlight (1983)
FUSE PANEL LOCATION (1986-89)
There are 3 fuse panels on this vehicle. The driver's side
fuse box is located behind the driver's kick panel. The passenger's
side fuse box is behind the passenger's side kick panel. The main fuse
and relay block is in the engine compartment.
PASSENGER COMPARTMENT FUSE BOX IDENTIFICATION (1986-89)
Fig. 3: Passenger Compartment Fuse Boxes Identification
Courtesy of Toyota Motor Sales, U.S.A., Inc.
* 1 - 15 Amp
Gauges, Warning Lights & Buzzer, Back-Up Lights & A/T
Overdrive System, Rear Window Defogger & Power Antenna
* 2 - 7.5 Amp
Clock & Open Door Warning Light (1987), Interior, Personal &
Door Courtesy Lights (1987), Trunk & Ignition Switch Lights
(1987)
* 3 - 15 Amp
Stoplights & Cruise Control Cancel Device
* 4 - 15 Amp
Tail, Park, License & Side Marker Lights, Glove Box Light &
Instrument Illumination
* 5 - 15 Amp
Cigarette Lighter & Digital Clock
* 6 - 7.5 Amp
Radio & Cassette Player
* 7 - 10 Amp
Turn Signal Lights
* 8 - 10 Amp
Outside Mirror Defogger
* 9 - Blank
* 10 - 10 Amp
Charging System
* 11 - 20 Amp
Wipers & Washers
* 12 - 15 Amp
Electric Sun Roof
* 13 - Blank
* 14 - 7.5 Amp
Charging System & Discharge Warning Light, Electronic Fuel
Injection & Electric Cooling Fans
* 15 - 30 Amp (Circuit Breaker)
Defogger
* 16 - 14 Amp (Circuit Breaker 1986)
* 16 - 30 Amp (Circuit Breaker 1987-89)
Power Door Locks
* 17 - 30 Amp (Circuit Breaker)
Power Windows
* 18 - 15 Amp
Anti-Lock Brake System & Foglights (1988-89)
* 19 - 10 Amp
Air Conditioning System
* 20 - 30 Amp (Circuit Breaker)
Heater
PASSENGER COMPARTMENT RELAY IDENTIFICATION (1986-89)
* A - Defogger
* B - Taillight Control
* C - Turn Signal Flasher
* D - Clutch Start
* E - Horn
* F - Heater
ENGINE COMPARTMENT BLOCK IDENTIFICATION (1986-89)
Fig. 4: Engine Compartment Fuse & Relay Block Identification
Courtesy of Toyota Motor Sales, U.S.A., Inc.
* 1 - 15 Amp
Headlights (Left)
* 2 - 15 Amp
Emergency Flashers & Horns
* 3 - 15 Amp
EFI System
* 4 - 7.5 Amp
Charging System & Discharge Warning Light
* 5 - 15 Amp
Headlights (Right)
* 6 - 30 Amp
Retractable Headlight System
* 7 - 15 Amp (1986-87)
* 7 - 20 Amp (1988-89)
Radio, Cassette Player & Power Antenna, Interior, Trunk,
Personal & Courtesy Lights (1988-89), Ignition Switch & Door
Warning Lights (1988-89), Clock (1988-89)
* 8 - Blank
* 9 - 30 Amp
Fan
ENGINE COMPARTMENT RELAY IDENTIFICATION (1986-89)
* A - Engine Main
* B - EFI Main
* C - Headlight Control
* D - Fan No. 1
FUSE PANEL LOCATION (1990-93)
There are 3 fuse panels on this vehicle. The driver's side
fuse box is located behind the driver's kick panel. The passenger's
side fuse box is behind the passenger's side kick panel. The main fuse
and relay block is in the engine compartment.
PASSENGER COMPARTMENT FUSE BOX IDENTIFICATION (1990-93)
Fig. 5: Driver's Side & Passenger's Side Fuse Boxes Identification
Courtesy of Toyota Motor Sales, U.S.A., Inc.
* 1 - 7.5 Amp
Charging System & Discharge Warning Light, Electric Cooling
Fans & EFI System
* 2 - 15 Amp
Cigarette Lighter & Digital Clock, Radio, Cassette Player &
Compact Disc Player
* 3 - 15 Amp
Stoplights & Cruise Control Cancel Device
* 4 - 15 Amp
Gauges, Warning Lights & Buzzer, Back-Up Lights & A/T
Overdrive System, Rear Window Defogger & Power Antenna, Tilt
Steering, Convertible Top Control
* 5 - 10 Amp
Turn Signal Lights
* 6 - 15 Amp
Electric Sun Roof
* 7 - 20 Amp
Wipers & Washers
* 8 - 15 Amp
Anti-Lock Brake System
* 9 - 15 Amp
Taillights, Parking Lights, Side Marker Lights, License
Lights, Instrument Lights, Glove Box Light
* 10 - Blank
* 11 - 10 Amp
Rear View Mirror
* 12 - 30 Amp (Circuit Breaker)
Defogger
* 13 - Blank
* 14 - 20 Amp
Front Foglights
* 15 - 10 Amp
Air Conditioning
* 16 - 40 Amp (Circuit Breaker)
Heater, A/C Control System
PASSENGER COMPARTMENT RELAY IDENTIFICATION (1990-93)
* A - Turn Signal Flasher
* B - Defogger
* C - Taillight Control
* D - Starter
* E - Heater Main
ENGINE COMPARTMENT MAIN BLOCK IDENTIFICATION (1990-93)
Fig. 6: Engine Compartment Main Fuse & Relay Block ID (Typical)
Courtesy of Toyota Motor Sales, U.S.A., Inc
* 1 - 15 Amp
Headlight (Left Side)
* 2 - 30 Amp
Retractable Headlight System
* 3 - 15 Amp
Headlight (Right Side)
* 4 - 15 Amp
EFI System
* 5 - 20 Amp
Radio, Cassette Player & Compact Disc Player, Power Antenna,
Clock, Interior & Personal Lights, Door Courtesy Lights,
Luggage Compartment Light, Trunk Light, Ignition Switch, Open
Door Warning Lights
* 6 - 15 Amp
Hazard Flashers & Horns
* 7 - 30 Amp (Circuit Breaker)
Cooling Fan
* 8 - 30 Amp (Circuit Breaker)
Condenser Cooling Fan
* 9 - 100 Amp (Circuit Breaker)
Charging System
* 10 - 40 Amp (Circuit Breaker)
AM2
* 10 - 30 Amp (1992-93)
Electronic Fuel Injection, Ignition System
* 11 - 30 Amp (Circuit Breaker)
AM1
* 11 - 40 Amp (1992-93)
Charging System, Electric Underhood Cooling Fan
* 12 - 60 Amp (Circuit Breaker)
Anti-Lock Brake System
ENGINE COMPARTMENT MAIN BLOCK RELAY IDENTIFICATION (1990-93)
* A - Fan No. 1
* B - Headlight Control
* C - EFI System
* D - Engine Main
CAUTIONS & WARNINGS
SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG SYSTEM)
NOTE: For information on air bag DIAGNOSIS & TESTING or DISPOSAL
PROCEDURES, see AIR BAGS article in the ACCESSORIES/SAFETY
EQUIPMENT Section.
When servicing vehicles equipped with Supplemental Restraint
Systems (SRS), always allow at least 20 seconds after turning ignition
switch to LOCK position and disconnecting the negative terminal cable
before beginning work on the SRS. The system has a back-up power
supply and may deploy air bag if these precautions are not followed.
