Image preview - the first page of the document
>> Download bodydime documenatation <<
Text preview - extract from the document
(Three-Dimensional Distance)
C
1,480
(58.27)
685 c
(26.97)
A 1,586
(62.44) D
761
(29.96)
L
1,274
913 (50.16)
K (35.94) B 564 302
BODY DIMENSIONS - Body Dimension Drawings
(22.20) (11.89)
ENGINE COMPARTMENT
BODY DIMENSION DRAWINGS
1,036
(40.79) b
1,383 753 l
(54.45) (29.65)
1,055
I 938 (41.54)
(36.93)
675
G a
(26.57) F
k
E 760
(29.92) i
H g
882 f
467 (34.72)
788
(18.39) (31.02) 809
(31.85) h
e
338
J (13.31)
j
C-K C-L C-k C-l
K-k L-l or or or or
c-k c-l c-K c-L
1,519 1,439 674 335 1,644 1,497 HINT: For symbols, capital letters indicate right side of vehicle,
(59.80) (56.65) (26.54) (13.19) (64.72) (58.94) small letters indicate left side of vehicle (Seen from rear).
mm (in.)
Symbol Name Hole dia. Symbol Name Hole dia.
A, a Front fender installation nut 6 (0.24) nut G, g Radiator support standard hole 10 (0.39)
B, b Front spring support hole-inner 11 (0.43) H, h Radiator support standard hole 10 (0.39)
C, c Hood hinge installation nut-rear 8 (0.31) nut I, i Radiator support standard hole 10 (0.39)
D Cowl top panel vehicle center mark 3 (0.12) R J, j Front crossmember standard hole 12 (0.47)
E, e Front side member standard hole 13 (0.51) K, k Front fender apron cut-out portion --
DI-3
F, f Front side member standard hole 17 (0.67) L, l Front fender installation nut 6 (0.24) nut
