                                                                                                                                                                                                                                     DI-6
                                                                                                                                                                     (Three-Dimensional Distance)
                                                                                                                      S
                                                                            s
                                                     l




                                                                                                                                                                                                                                     BODY DIMENSIONS - Body Dimension Drawings
                                                                             2,222                  1,364
                                                                                                   (53.70)           1,062
                                                                            (87.48)                                 (41.81)
                                                          1,786




                                                                                                                                                                                                    BODY OPENING AREAS (Rear View)
                                                         (70.31)
                                                                                                                                            T

                                                                                  1,388
                                                                        t        (54.65)
                                                                                             1,266
                                                                                            (49.84)                   V
                                                                   v

                                                                                                                              U

                                                                                      u




   HINT: For symbols, capital letters indicate right side of vehicle,
   small letters indicate left side of vehicle (Seen from rear).
                                                                                                                                                             mm (in.)
Symbol                                   Name                               Hole dia.      Symbol                                          Name          Hole dia.
  L, l     Center body pillar assembly mark                                     --          U, u             Rear floor finish plate installation hole   8.5 (0.335)
  S, s     Back door hinge installation hole-outer                           11 (0.43)      V, v             Shock absorber installation hole            16 (0.63)
  T, t     Quarter panel standard hole                                       10 (0.39)       --                                              --              --
