Image preview - the first page of the document
>> Download bodyopen documenatation <<
Text preview - extract from the document
DI-4
(Three-Dimensional Distance)
A
1,189
(46.81) a
888
(34.96) i j
1,568
BODY DIMENSIONS - Body Dimension Drawings
645
(61.73) (25.39)
B e
1,405
(55.31)
b 1,150
1,192
(45.28)
(46.93)
c
BODY OPENING AREAS (Side View: Front)
1,022
1,079
1,283 (42.48) (40.24)
(50.51)
958 k
(37.72)
d
872
f (34.33)
h
g
HINT: For symbols, capital letters indicate right side of vehicle,
small letters indicate left side of vehicle (Seen from rear).
Vehicle Dimensions Left $ Right
E-f E-h E-j F-j F-k H-i J-k
E-e F-f G-g H-h I-i J-j K-k or or or or or or or
e-F e-H e-J f-J f-K h-I j-K
1,359 1,535 1,537 1,546 1,260 1,404 1,559 1,708 1,807 1,525 1,950 1,776 1,808 1,710
(53.50) (60.43) (60.51) (60.87) (49.61) (55.28) (61.38) (67.24) (71.14) (60.04) (76.77) (69.92) (71.18) (67.32)
mm (in.)
Symbol Name Hole dia. Symbol Name Hole dia.
A, a Roof panel / Front body pillar adjoining portion -- G, g Rocker panel assembly mark --
B, b Cowl top panel / Front body pillar adjoining portion -- H, h Rocker panel assembly mark --
C, c Front door hinge installation nut-rear 8 (0.31) nut I, i Roof side rail assembly mark --
D, d Front door hinge installation nut-rear 8 (0.31) nut J, j Center body pillar assembly mark --
E, e Front body pillar assembly mark -- K, k Cneter body pillar assembly mark --
F, f Front body pillar assembly mark -- -- -- --
