(Three-Dimensional Distance) (Two-Dimensional Distance)
Front Front
L RH L RH
H H
a A A
635 696 a 285 350 683
(25.00) (27.40) (11.22) (13.78) (26.89)
920 460
BODY DIMENSIONS - Body Dimension Drawings
b B 577 B
(36.22) (18.11)
(22.72) b
828 862
(32.60) (33.90)
591
980 1,115 (23.27)
(38.58) (43.90)
639 634
(25.16) (24.96)
693
FRONT FRAME
(27.28)
486 C 58
c 243
c (19.13) (2.28)
d C 332 (9.57) 332
663 D 0 0
(26.10) d (13.07) (13.07) D
830 114 415
e (32.68) E E
(4.49) e (16.34)
Imaginary
Standard
a b e d c C D E B A a b e d c C D E B A Line
70 37 61 55 63 63 55 61 37 67
(2.76) (1.46) (2.40) (2.17) (2.48) (2.48) (2.17) (2.40) (1.46) (2.64)
mm (in.)
Symbol Name Hole dia. Symbol Name Hole dia.
A, a Front frame standard hole 13 (0.51) D, d Front frame standard hole 13 (0.51)
B, b Front frame standard hole 13 (0.51) E, e Lower control link installation hole - lower 15 (0.59)
DI-9
C, c Front frame standard hole 13 (0.51) -- -- --
