RE-14                                         BODY PANEL REPLACEMENT

     COWL TOP SIDE INNER PANEL (ASSY)
REMOVAL (With the cowl top side outer panel removed.)


                                --1

                                                      Make Incision




         --3                                  --2                     --1




                                      -- 11



                                                                       Cut with disc sander etc.




                                                                      --4
                                                                                                     --3


                                                                                               --2




                                                                            --3



1.    Make an incision in the cowl top panel and bend as
      shown above. Drill out the spot welds and separate the
      cowl top side inner panel.
                                             BODY PANEL REPLACEMENT                                 RE-15
INSTALLATION

                          --1

                                                  Butt Weld




     --3                               --2                    --1




                                     -- 11




                                                                    Tack Weld (15 mm)




                                                                    --4
                                                                                              --3


                                                                                        --2




                                                                          --3

     mm        in.
     15       0.59

1.   Temporarily install the new parts and measure each
     part in accordance with the body dimension diagram.
