Image preview - the first page of the document



>> Download quart documenatation <<

Text preview - extract from the document

RE-42                                             BODY PANEL REPLACEMENT

     QUARTER PANEL (CUT): 4-Door Right Side,
     5-Door
REMOVAL
                          Cut and Join Location


                                                                                 [Cut and Join Location]



                                             -- 25
              120 mm




     RH:   -- 20
     LH:   -- 21




                                           -- 16
     120 mm

                                                          --9
                           Cut and Join Location                                 Cut and Join Location



                            [Cut and Join Locations]
                                                                                   --5                     110 mm



                                                                           --2
                                                                                                  --6




                                                                           --5




                                                                           --6




1.     Cut and join the parts at the locations as shown above.
                                                                                                  mm           in.
                                                                                                  110          4.33
                                                                                                  120          4.72
                                             BODY PANEL REPLACEMENT                                                RE-43
INSTALLATION

                              Butt Weld




                                                              --3

                                   --8        -- 19
                      --7                                                                   Body Sealer



     RH:     -- 17
     LH:     -- 19
                                                                               about 5 mm




 Butt Weld                                -- 21


                                                        --9
                               Body Sealer


                                                                                       Butt Weld




                                                                                 --5


                                                                           --2
                                                                                                --6




                                                                        --5




                                                                         --6




     mm              in.
      5              0.20

1.    Before temporarily installing the new parts, apply       2.   Temporarily installing the new parts, check the fit of
      body sealer to the wheel arch.                                the slide door, back door and rear combination light.
HINT:
1) Apply body sealer about 5 mm (0.20 in.) from the
    flange, avoiding any oozing.
2)    Apply sealer evenly, about 3 - 4 mm (0.12 - 0.16 in.)
      in diameter.
3)    For other sealing points, refer to seciton AR.
