Image preview - the first page of the document



>> Download quart0 documenatation <<

Text preview - extract from the document

RE-44                                        BODY PANEL REPLACEMENT

     QUARTER PANEL (CUT-P)
REMOVAL




                                                                Cut and Join Location




                                      --5


                                                       --9




                                                               --5




                                                               --6




1.    Cut and join the parts at the location as shown above.
                                            BODY PANEL REPLACEMENT                                                  RE-45
INSTALLATION




                                                                                               Body Sealer




                                                                                  about 5 mm
                                                              Butt Weld




                                                                  Body Sealer


                                   --7


                                                      --9




                                                                      --5




                                                                      --6




     mm         in.
     5         0.20

1.   Before temporarily installing the new parts, apply      2.     Temporarily installilng the new parts, check the fit of
     body sealer to the wheel arch.                                 the back door.
HINT:
1) Apply body sealer about 5 mm (0.20 in.) from the
    flange, avoiding any oozing.
2)   Apply sealer evenly, about 3 - 4 mm (0.12 - 0.16 in.)
     in diameter.
3)   For other sealing points, refer to section AR.
